膈肌电刺激联合阈值压力负荷呼吸训练对亚急性期颈段脊髓损伤患者肺功能的影响

黄乐乐; 刘孟

doi:10.16766/j.cnki.issn.1674-4152.003578

膈肌电刺激联合阈值压力负荷呼吸训练对亚急性期颈段脊髓损伤患者肺功能的影响

doi: 10.16766/j.cnki.issn.1674-4152.003578

黄乐乐¹,
刘孟^2, ,

1.
蚌埠医科大学第一附属医院重症医学科，安徽蚌埠 233004
2.
中国科技大学附属第一医院康复医学科，安徽合肥 230001

基金项目:

安徽省临床医学研究转化专项基金项目 202304295107020073

详细信息

通讯作者:
刘孟，E-mail: liumeng5238@126.com

中图分类号: R651.2 R454
计量
- 文章访问数: 124
- HTML全文浏览量: 54
- PDF下载量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2023-10-19
- 网络出版日期: 2024-09-05

Effects of low frequency electric stimulation on diaphragmatic muscle combined with threshold inspiratory muscle training on lung function in patients with sub-acute traumatic cervical spinal cord injury

HUANG Lele¹,
LIU Meng^{2
, ,}

1.
Department of Critical Care Medicine, the First Affiliated Hospital of Bengbu Medical University, Bengbu, Anhui 233004, China

摘要

摘要: 目的观察亚急性期创伤性颈段脊髓损伤患者进行膈肌低频脉冲电刺激联合阈值压力负荷呼吸训练对患者肺功能和肺部感染发生率的影响。方法采用随机数字表法将2020年7月—2022年6月蚌埠医科大学第一附属医院收治住院的亚急性期创伤性颈段脊髓损伤患者40例分为对照组(20例)和实验组(20例)，对照组在常规治疗的基础上接受阈值压力负荷呼吸功能训练，实验组在对照组的基础上给予膈肌低频脉冲电刺激。分别于治疗前及治疗3周后评估患者肺功能[用力肺活量(FVC)、FVC占预计值的百分比(FVC%pred)、第一秒用力呼气容积(FEV₁)及FEV₁占预计值的百分比(FEV₁%pred)]的变化；治疗后随访3个月，统计肺部感染的发生率。结果与治疗前比较，2组患者治疗3周后的FVC、FVC%pred、FEV₁及FEV₁%pred均有明显提高(P < 0.01)；治疗3周后，实验组患者FVC、FVC%pred、FEV₁及FEV₁%pred均高于对照组，差异有统计学意义(P < 0.01)。治疗3个月后，实验组患者的肺部感染发生率为50.0%(10/20)，对照组为80.0%(16/20)，实验组患者肺部感染发生率显著低于对照组(χ²=3.956, P=0.047)。结论膈肌低频脉冲电刺激联合阈值压力负荷呼吸训练能有效改善亚急性期创伤性颈段脊髓损伤患者的肺功能，降低肺部感染的发生率。
- 低频脉冲电刺激 /
- 阈值压力负荷呼吸训练 /
- 颈段脊髓损伤 /
- 肺功能
Abstract: Objective To observe the effectiveness of low frequency electric stimulation on diaphragmatic muscle combined with threshold inspiratory muscle training on lung function and incidence of lung infections in patients with sub-acute traumatic cervical spinal cord injury. Methods A total of 40 patients with sub-acute traumatic cervical spinal cord injury in Department of Critical Care Medicine of the First Affiliated Hospital of Bengbu Medical University from July 2020 to June 2022 were assigned to the control and experimental groups (20 for each group) by the random number table. The control group received threshold inspiratory muscle training on the basis of conventional treatment, and the experimental group was given low frequency electric stimulation on diaphragmatic muscle on the basis of the control group. The patients' lung functions [forceful lung volume (FVC), FVC as a percentage of the predicted value (FVC%pred), first-second forceful expiratory volume (FEV₁), and FEV₁ as a percentage of the predicted value (FEV₁%pred)] were evaluated before and after 3 weeks of treatment. The incidence of pulmonary infections was followed up at 3 months after treatment. Results After three-week training, compared with before the training, FVC, FVC%pred, FEV_l and FEV₁%pred in two groups obviously improved (P < 0.01). Comparing with the control group, FVC, FVC%pred, FEV_l and FEV₁%pred in experimental group were significantly high (P < 0.01). After 3 months of treatment, the incidence of lung infection was significantly lower in the experimental group than in the control group [50.0% (10/20) vs. 80.0% (16/20), χ²=3.956, P=0.047]. Conclusion Low frequency electric stimulation on diaphragmatic muscle combined with threshold inspiratory muscle training can significantly improve on lung function in patients with sub-acute traumatic cervical spinal cord injury, and its effect is better than the simple respiratory training.
- Low frequency pulse electrical stimulation /
- Threshold inspiratory muscle training /
- Cervical spinal cord injury /
- Lung function

HTML全文

表 1 2组创伤性颈段脊髓损伤患者一般情况比较

Table 1. Comparison of general conditions between two groups in patients with traumatic cervical spinal cord injury

组别	例数	性别(例)		年龄 (x±s, 岁)	BMI (x±s)	病程 (x±s, d)	ASIA分级(例)				损伤平面(例)
组别	例数	男性	女性	年龄 (x±s, 岁)	BMI (x±s)	病程 (x±s, d)	A	B	C	D	C₄	C₅	C₆	C₇	C₈
对照组	20	16	4	38.23±9.56	20.95±2.04	16.33±2.14	2	9	5	4	1	3	10	5	1
实验组	20	15	5	39.55±10.58	20.75±1.99	16.51±2.35	3	10	4	3	1	4	9	4	2
统计量		<0.001^a		0.414^b	0.314^b	0.253^b	0.694^c				0.640^a
P值		0.999		0.681	0.755	0.801	0.488				0.959
注：^a为χ²值，^b为t值, ^c为Z值。

下载: 导出CSV

表 2 2组创伤性颈段脊髓损伤患者治疗前后FVC比较(x±s)

Table 2. Comparison of FVC before and after treatment in two groups of patients with traumatic cervical spinal cord injury (x±s)

组别	例数	FVC(L)		t值	P值	FVC%pred(%)		t值	P值
组别	例数	治疗前	治疗后	t值	P值	治疗前	治疗后	t值	P值
实验组	20	1.78±0.12	3.00±0.13	35.211	<0.001	41.32±6.39	68.7±10.38	10.536	<0.001
对照组	20	1.77±0.12	2.23±0.11	13.987	<0.001	41.17±6.12	58.7±7.03	6.651	<0.001
统计量		0.264^a	1 601.500^b			0.076^a	57.793^b
P值		0.794	<0.001			0.940	<0.001
注: ^a为t值，^b为F值。

下载: 导出CSV

表 3 2组创伤性颈段脊髓损伤患者治疗前后FEV₁比较(x±s)

Table 3. Comparison of FEV1 before and after treatment in two groups of patients with traumatic cervical spinal cord injury (x±s)

组别	例数	FEV₁(L)		t值	P值	FEV₁%pred(%)		t值	P值
组别	例数	治疗前	治疗后	t值	P值	治疗前	治疗后	t值	P值
实验组	20	1.66±0.10	2.52±0.18	35.211	<0.001	45.73±7.55	68.79±17.85	10.536	<0.001
对照组	20	1.64±0.07	1.93±0.16	13.987	<0.001	46.22±6.86	56.71±14.12	6.651	<0.001
统计量		0.733^a	115.284^b			0.215^a	22.216^b
P值		0.468	<0.001			0.831	<0.001
注: ^a为t值，^b为F值。

下载: 导出CSV

表 4 2组创伤性颈段脊髓损伤患者治疗前后肺功能参数变化量比较(x±s)

Table 4. Comparison of pulmonary function parameters before and after treatment in patients with traumatic cervical spinal >cord injury between two groups (x±s)

组别	例数	FVC		FEV₁
组别	例数	ΔFVC(L)	ΔFVC%pred(%)	ΔFEV₁(L)	ΔFEV₁%pred(%)
实验组	20	1.22±0.07	27.38±3.65	0.86±0.19	23.06±3.41
对照组	20	0.46±0.05	17.53±4.45	0.29±0.18	10.49±2.32
t值		39.511	7.654	9.740	13.630
P值		<0.001	<0.001	<0.001	<0.001
注：Δ为各项指标治疗前后的变化值。

下载: 导出CSV

参考文献(16)

[1]	冯世庆. 脊髓损伤神经修复时间窗的相关问题[J]. 中华创伤杂志, 2019, 35(8): 673-676. FENG S Q. Certain issues related to time window for neurorestoratology following spinal cord injury[J]. Chinese Journal of Trauma, 2019, 35(8): 673-676.
[2]	刘趁心, 孟冰, 杨照, 等. 急性重度颈脊髓损伤患者临床特征分析及远期死亡危险因素初探[J]. 中国脊柱脊髓杂志, 2019, 29(3): 247-253. https://www.cnki.com.cn/Article/CJFDTOTAL-ZJZS201903010.htm LIU C X, MENG B, YANG Z, et al. Analysis of clinical characteristics and risk factors of long-term death in patients with acute severe cervical spinal cord injury[J]. Chinese Journal of Spine and Spinal Cord, 2019, 29(3): 247-253. https://www.cnki.com.cn/Article/CJFDTOTAL-ZJZS201903010.htm
[3]	王凤霞, 吴霜. 急性脊髓损伤后继发肺损伤发生机制的研究进展[J]. 中国康复, 2018, 33(5): 417-421. https://www.cnki.com.cn/Article/CJFDTOTAL-ZLKF201805024.htm WANG F X, WU S. Secondary lung injury after acute spinal cord injury mechanism research progress[J]. Chinese Journal of Rehabilitation, 2018, 33(5): 417-421. https://www.cnki.com.cn/Article/CJFDTOTAL-ZLKF201805024.htm
[4]	苏日罕, 包亮. 急性重度颈脊髓损伤患者临床特征及早期死亡的危险因素分析[J]. 颈腰痛杂志, 2021, 42(4): 466-469. https://www.cnki.com.cn/Article/CJFDTOTAL-JYTZ202104007.htm SU R H, BAO L. Analysis of clinical characteristics and risk factors of early death in patients with acute severe cervical spinal cord injury[J]. The Journal of Cervicodynia and Lumbodynia, 2021, 42(4): 466-469. https://www.cnki.com.cn/Article/CJFDTOTAL-JYTZ202104007.htm
[5]	康海琼, 周红俊, 刘根林, 等. 脊髓损伤神经学分类国际标准检查表2019版最新修订及解读[J]. 中国康复理论与实践, 2019, 25(8): 983-985. https://www.cnki.com.cn/Article/CJFDTOTAL-ZKLS201908021.htm KANG H Q, ZHOU H J, LIU G L, et al. Modification and Interpretation of the 2019 International Standards for Neurological Classification of Spinal Cord Injury Worksheet[J]. Chinese Journal of Rehabilitation Theory and Practice, 2019, 25(8): 983-985. https://www.cnki.com.cn/Article/CJFDTOTAL-ZKLS201908021.htm
[6]	FAYSSOIL A, BEHIN A, OGNA A, et al. Diaphragm: pathophysiology and ultrasound imaging in neuromuscular disorders[J]. J Neuromuscul Dis, 2018, 5(1): 1-10. doi: 10.3233/JND-170276
[7]	刘孟, 李雪明. 阈值压力负荷呼吸训练对创伤性颈部脊髓损伤气管切开患者肺功能的影响[J]. 心肺血管病杂志, 2023, 42(4): 328-332. https://www.cnki.com.cn/Article/CJFDTOTAL-XFXZ202304007.htm LIU M, LI X M. Effects of threshold inspiratory muscle training on lung function in patients with traumatic cervical spinal cord injury and undergoing tracheotomy[J]. Journal of Cardiovascular and Pulmonary Diseases, 2023, 42(4): 328-332. https://www.cnki.com.cn/Article/CJFDTOTAL-XFXZ202304007.htm
[8]	贺婷婷, 贝宴屏, 徐国栋. 肺综合康复训练对肺癌放疗患者肺功能和症状的影响[J]. 中华全科医学, 2021, 19(1): 120-123. doi: 10.16766/j.cnki.issn.1674-4152.001746 HE T T, BEI Y P, XU G D. Effect of comprehensive lung rehabilitation training on lung function and syndrome in patients with lung cancer undergoing radiotherapy[J]. Chinese Journal of General Practice, 2021, 19(1): 120-123. doi: 10.16766/j.cnki.issn.1674-4152.001746
[9]	袁国琴. 呼吸训练器对胸外科术后患者肺功能恢复的影响[J]. 中华全科医学, 2020, 18(3): 509-512. doi: 10.16766/j.cnki.issn.1674-4152.001285 YUAN G Q. Effect of respiratory trainer on lung function recovery in patients after thoracic surgery[J]. Chinese Journal of General Practice, 2020, 18(3): 509-512. doi: 10.16766/j.cnki.issn.1674-4152.001285
[10]	YATES B A, BROMN R, PICARD G, et al. Improved pulmonary function is associated with reduced inflammation after hybrid whole-body exercise training in persons with spinal cord injury[J]. Exp Physiol, 2023, 108(3): 353-360. doi: 10.1113/EP090785
[11]	唐文庆, 张瑞媞, 殷稚飞. 体外膈肌起搏在膈肌功能障碍中的应用[J]. 中华物理医学与康复杂志, 2018, 40(11): 871-874. https://cdmd.cnki.com.cn/Article/CDMD-10344-1023062175.htm TANG W Q, ZHANG R T, YIN Z F. Application of external diaphragm pacing in diaphragmatic dysfunction[J]. Chinese Journal of Physical Medicine and Rehabilitation, 2018, 40(11): 871-874. https://cdmd.cnki.com.cn/Article/CDMD-10344-1023062175.htm
[12]	朱秀华, 朱永刚, 王银龙, 等. 体外膈肌起搏器联合呼吸训练对脑卒中气管切开患者肺功能的影响[J]. 中国康复医学杂志, 2021, 36(8): 973-977. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGKF202108013.htm ZHU X H, ZHU Y G, WANG Y L, et al. Effects of external diaphragm pacemaker combined with respiratory training on pulmonary function in stroke patients with tracheotomy[J]. Chinese Journal of Rehabilitation Medicine, 2021, 36(8): 973-977. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGKF202108013.htm
[13]	KEOGH C, SAAVEDRA F, DUBO S, et al. Non-invasive phrenic nerve stimulation to avoid ventilator- induced diaphragm dysfunction in critical care[J]. Artif Organs, 2022, 46(10): 1988-1997. doi: 10.1111/aor.14244
[14]	SHIN J C, HAN E Y, CHO K H, et al. Improvement in pulmonary function with short-term rehabilitation treatment in spinal cord injury patients[J]. Sci Rep, 2019, 9(1): 17091. DOI: 10.1038/s41598-019-52526-6.
[15]	赵茜叶, 侍苏杰, 徐海燕, 等. 肺炎支原体肺炎患儿肺功能变化与慢性咳嗽的相关性[J]. 中华实用儿科临床杂志, 2019, 34(4): 270-273. https://www.cnki.com.cn/Article/CJFDTOTAL-JYGZ202212016.htm ZHAO Q Y, SHI S J, XU H Y, et al. The correlation between the changes in pulmonary function and chronic cough in children with Mycoplasma pneumoniae pneumonia[J]. Chinese Journal of Applied Clinical Pediatrics, 2019, 34(4): 270-273. https://www.cnki.com.cn/Article/CJFDTOTAL-JYGZ202212016.htm
[16]	杨宁, 李晓兵, 侯丽敏, 等. 徒手咳嗽辅助技术联合主动呼吸循环技术对脑卒中后肺部感染患者肺功能的影响[J]. 中国康复, 2023, 38(9): 529-533. https://www.cnki.com.cn/Article/CJFDTOTAL-ZLKF202309004.htm YANG N, LI X B, HOU L M, et al. Effects of manual cough assist techniques combined with active cycle of breathing techniques on pulmonary function of patients with pulmonary infection after stroke[J]. Chinese Journal of Rehabilitation, 2023, 38(9): 529-533. https://www.cnki.com.cn/Article/CJFDTOTAL-ZLKF202309004.htm
